OKM Rover C4
£11,980.00
- Bestseller: 3D ground scanner and metal detector
- Detection Depth: With this technology customers found objects down to 25 m (82 ft) deep
- Use Cases: Treasure hunting, archaeology, natural gold prospection
- Operating Modes: 3D Ground Scan, Pinpointer, Magnetometer, Mineral Scan
- Detectable Objects: Natural gold minerals, treasure chests, jewelry, militaria
The ground scanner Rover C4 is an easy-to-use multi-purpose treasure and void detector. The detector supports treasure hunters and archaeologists in finding long-time buried treasures such as relict, coins, vessels and jewelry as well as underground structures like tunnels, caves, chambers and graves. The measured data can be viewed and analyzed in the Visualizer 3D Studio Software.
Benefits and Features of Rover C4
- Operational touchscreen with alternative hardware buttons
- Graphical user interface in many different languages
- Improved multilevel LED lighting for detector usage in darkness
- Exchangeable probes: Standard Probe and Super Sensor
- Immediate basic target discrimination thanks to LED Orbit
- Supported operating modes: 3D Ground Scan, Pinpointer, Mineral Scan, Magnetometer
- Integrated battery
- Simplified wireless data transfer
- 4 separate memory areas to store measuring data
- Including detection software Visualizer 3D Studio Standard Edition
Control unit
- Dimensions (H x W x D): 390 x 300 x 140 mm
- Weight: about 1.5 kg
- Input voltage (max.): 19 V DC, 3.16 A, 60 W
- Processor / Main CPU: Cortex M3, 32 MHz
- Processor / Slave CPU: Cortex M0, 24 MHz
- Display: 3.5” Resistive touch, 480 x 320 Pixel
- Display CPU: Cortex M3, 32 MHz, 128 KB RAM
- Data memory: 4 GB
- Sample rate: 1024 values / second
- Measurement resolution: 16 bit
- Operating temperature: –10°C – 60°C
- Storage temperature: –20°C – 70°C
- Audio: Internal speaker / Bluetooth
- Waterproof: No
- Air humidity: 5% – 75%
Standard Probe
- Weight: 0.4 kg
- Length: 445 mm
- Diameter tube / LED Orbit: 35 mm / 65 mm
- Technology: SCMI-15-D
Super Sensor
- Weight: 0.9 kg
- Length: 960 mm
- Diameter tube / LED Orbit: 50 mm / 65 mm
- Technology: SCMI-15-D
Data transmission
- Technology: Bluetooth 5.1
- Frequency: 2.402 – 2.480 GHz
- Maximum Transfer Rate: 1 Mbps
- Maximum Transmitting Power: +8 dBm
- Maximum Range: approx. 10 m
Computer minimum requirements
- Interface (data transmission): USB 2.0
- Free disk space: 250 MB
- Working memory (RAM): 2 GB
- Display: 1920 x 1080
- Processor: 1.2 GHz
- Graphics card: 1 GB RAM, OpenGL 3.3
- Operating system: Windows 10
The technical data are average values. Minor deviations are possible during operation.
